Marine Cable Gland TJ Type
Material: Brass, chromium plated
Product Certification: CE certificationand ISO9001.
Protection Degree: IP54
Working temperature: -40℃to 110℃, short time up to 120℃.
Products
Thread Size: TJ
Material: Brass, chromium plated
Product Certification: CE certificationand ISO9001.
Protection Degree: IP54
Working temperature: -40℃to 110℃, short time up to 120℃.
Function: Can be used in meter,machines,transportation,medicine,and all types of unarmored marine electrical cable fittings.
More options: Customization is accept.Welcome to inquire.
|
Product Code |
Cable Range (mm) |
d (mm) |
D (mm) |
d1(mm) |
D1(mm) |
H1(mm) |
H(mm) |
|
JX-TJ8 |
5-7 |
8 |
M16*1 |
M14*1 |
20 |
9 |
32 |
|
JX-TJ13 |
6-12 |
13 |
M20*1 |
M18*1 |
24 |
10 |
35 |
|
JX-TJ16 |
11-15 |
16 |
M27*1.5 |
M22*1.5 |
31.5 |
12 |
40 |
|
JX-TJ19 |
14-18 |
19 |
M30*1.5 |
M27*1.5 |
34.5 |
12 |
42 |
|
JX-TJ24 |
17-23 |
24 |
M35*1.5 |
M30*1.5 |
39.6 |
12 |
44 |
|
JX-TJ28 |
22-27 |
28 |
M42*2 |
M36*1.5 |
46.5 |
15 |
46 |
|
JX-TJ34 |
26-33 |
34 |
M47*2 |
M42*2 |
54 |
15 |
49 |
|
JX-TJ42 |
32-41 |
42 |
M55*2 |
M52*2 |
62 |
15 |
54 |
|
JX-TJ50 |
40-49 |
50 |
M62*2 |
M58*27 |
68.5 |
15 |
56 |
|
JX-TJ58 |
48-57 |
58 |
M71*2 |
M68*2 |
77.5 |
20 |
56 |
The Drawing of Marine Cable Gland:
